Specification
| Main Feature | ||
| Type | Gigabit Smart Switch | |
| Network Standard | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p | |
| Access Method | 10BASE-T: UTP/STP category 3, 4, 5 cables (maximum 100m) 100BASE-TX/1000Base-T: UTP/STP category 5, 5e or above cable (maximum 100m) 100BASE-FX: MMF, SMF 1000BASE-X: MMF, SMF |
|
| Data Transmission Rate | Switching Capacity: 20 Gbps Packet Forwarding Rate: 14.9 Mpps Packet Buffer Memory: 4.1 Mbit Jumbo Frame: 9 KB |
|
| MAC Address Table | 8K | |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
|
| Hardware Features | ||
| Interface | 8× 10/100/1000 Mbps RJ45 Ports, all supporting PoE+ (Auto-Negotiation/Auto MDI/MDIX) 2× 100/1000 Mbps SFP Slots |
|
| Power Supply | 100-240 V AC~50/60 Hz PoE Power: 150 W |
|
| Dimensions (L x W x H) | 11.6 x 7.1 x 1.7 in (294 x 180 x 44 mm) |
|
| Manufacture Warranty | ||
| Warranty | 1 Year | |
