Specification
| Main Feature | ||
| Type | Gigabit Smart Switch | |
| Port | Standard: 802.3at/802.3af compliant PoE Ports: Port1- Port 8 PoE Power Budget: 63W |
|
| Network Standard | Compatible With IEEE 802.3af/at Compliant PDs EEE802.3x Flow Control 802.1p/DSCP QoS IGMP Snooping |
|
| Access Method | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-X MMF, SMF |
|
| Data Transmission Rate | Switching Capacity: 20 Gbps Packet Forwarding Rate: 14.88 Mpps Jumbo Frame: 16 KB |
|
| MAC Address Table | 4K | |
| Environment | Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5%~90% non-condensing |
|
| Hardware Features | ||
| Interface | 8 PoE+ 10/100/1000Mbps RJ45 Ports 1 10/100/1000Mbps RJ45 Port 1 Gigabit SFP Slot |
|
| Power Supply | External Power Adapter(Output: 53.5VDC / 1.31A) | |
| Dimensions (L x W x H) | 209 × 126 × 26 mm | |
| Manufacture Warranty | ||
| Warranty | 1 Year | |
