Specification
| Key Features | ||
| Data Rate | WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps WiFi 7 (802.11be) (2.4GHz): up to 688 Mbps WiFi 7 (802.11be) (5GHz): up to 2882 Mbps |
|
| Antenna | External fixed antenna x4 | |
| Button | WPS Button, Reset Button, Power Button | |
| Frequency | 2.4 GHz 5 GHz |
|
| Wireless | UTF-8 SSID WiFi MAC Address Filter Maximum MAC Filters: 64 Wireless Scheduler Airtime Fairness RADIUS Client Universal Beamforming Explicit Beamforming |
|
| Interface | File System : HFS+, NTFS, vFAT, ext2, ext3, ext4 Safely Remove Disk Download Master Media Server Time Machine Samba Server FTP Server Shared Folder Privileges |
|
| Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) WiFi 7 (802.11be) IPv4 IPv6 |
|
| Encryption | AiProtection VPN WPS support, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise WPS Let’s Encrypt DNS-over-TLS SSH Security Scan Firewall Maximum Firewall Keyword Filter : 64 Maximum Firewall Network Service Filter : 32 Maximum Firewall URL Filter : 64 |
|
| Ports | 1x 2.5G for WAN/LAN, 1x 1G for WAN/LAN, 3 x 1G LAN, USB 3.2 Gen 1 x 1 |
|
| Others | Processor: 2.0 GHz Quad-core Processor Memory: 256 MB Flash and 1 GB RAM Boosts Speed: OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 4096-QAM high data rate 20/40/80/160 MHz bandwidth AiMesh: Primary AiMesh Router AiMesh Node Game: Game Boost / Acceleration Gear Accelerator OpenNAT (Game Profile) Gaming Port Parental Control: Allow you to block access to unwanted websites and apps. Web & Apps Filters Time Scheduling Safe Browsing Customized Internet Schedule • Maximum Parental Control Profile : 64 • Maximum Parental Control Content Cilter Rule : 64 AiProtection: AiProtection Pro • Router Security Assessment • Malicious Site Blocking • Two-Way IPS • Infected Device Prevention and Blocking VPN: Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion Traffic Control: Adaptive QoS • Bandwidth Monitor • Bandwidth Limiter — Maximum Bandwidth Limiter Rule: 32 Traditional QoS Traffic Monitor • Real-time Traffic Monitor • Wired Traffic Monitor • Wireless Traffic Monitor Traffic Analyzer • Traffic Analysis Period: Daily, Weekly, Monthly • Website History WAN: Internet connection Type: PPPoE, PPTP, L2TP, Automatic IP, Static IP 3G / 4G LTE dongle Port forwarding • Maximum Port Forwarding Rule : 64 Port triggering • Maximum Port Triggering Rule : 32 DMZ DDNS NAT Passthrough: PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay LAN: DHCP Server IGMP Snooping IPTV Manually Assign IP Address • Maximum Manually Assign IP Address Rule : 64 Wake on LAN (WOL) |
|
| Power Source | ||
| Power Mode | AC Input : 110V~240V(50~60Hz) DC Output : 12 V with max. 2 A current |
|
| Physical Dimension | ||
| Dimension | 274 x 168 x 205 mm | |
| Weight | 561g | |
| Color | Black | |
| Manufacturer warranty | ||
| Warranty | 2 Year | |
