Specification
| Main Feature | ||
| Network Standard | IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3af/at | |
| Advanced Functions | Lightning Protection: 6KV | |
| Transmission Method | Recommended: CAT5/5e UTP or better | |
| Data Transmission Rate | Forwarding Rates: 6.55 Mpps Switching capacity: 8.8 Gbps |
|
| MAC Address Table | 16K | |
| Environment | Operating Temperature: 0℃~45℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
|
| Hardware Features | ||
| Interface | 24 * 10/100 Base-TX Ethernet ports (Data/Power) 2 * 10/100/1000 Base-T Ethernet ports (Data) 1 * 1000 Base-X SFP port (Combo) |
|
| LED | 24 * Link/Act LEDs 1 * G1 LED 1 * G2/SFP2 LED 1 * PoE-MAX LED 1 * Power LED |
|
| Power Supply | Ports 1-24 support standard IEEE802.3af/at 30W output per PoE port 370W output of the total PoE Power |
|
| Dimensions (L x W x H) | 440.0mmx178.8mmx44.0mm | |
| Manufacture Warranty | ||
| Warranty | 01-Year Warranty | |
